Apple iPhone 7 Plus 32GB Specifications

General Information

• Model: Apple iPhone 7 Plus (A1661, A1784, A1785, A1786)
• Release Date: September 16, 2016
• Operating System: iOS 10.0.1, upgradable to iOS 15.8.1

Design and Build

• Dimensions: 6.23 x 3.07 x 0.29 inches (158.2 x 77.9 x 7.3 mm)
• Weight: 6.63 oz (188 g)
• Build: Aluminum unibody with ion-strengthened glass front, oleophobic coating
• Water Resistance: IP67 rating (splash, water, and dust resistant, up to 1 meter for 30 minutes)
• Finish: Jet Black features a high-gloss finish via a nine-step anodization process; prone to micro-abrasions, case recommended

Display

• Type: Retina HD, LED-backlit IPS LCD, Multi-Touch
• Size: 5.5 inches (diagonal)
• Resolution: 1920 x 1080 pixels, 401 ppi
• Brightness: Up to 625 nits (typical), 705 nits (maximum)
• Features:
  • Wide color gamut (P3)
  • 3D Touch for pressure-sensitive interactions
  • 1300:1 contrast ratio
  • Fingerprint-resistant coating
  • True Tone display with four-channel ambient light sensor

Performance

• Processor: Apple A10 Fusion (64-bit, 16 nm)
  • Quad-core CPU (2.34 GHz Hurricane dual-core + 1.1 GHz Zephyr dual-core)
  • Embedded M10 motion coprocessor
• RAM: 3 GB LPDDR4
• GPU: PowerVR Series 7XT Plus (six-core), up to 50% faster graphics than predecessor
• Storage: 32 GB (no microSD card slot)
• Performance Notes:
  • 32 GB variant has slower write speeds (341 MB/s) compared to 128 GB/256 GB models (42 MB/s)
  • Enhanced multitasking and gaming performance due to increased RAM compared to iPhone 7

Camera

• Rear Camera (Dual):
  • 12 MP Wide, f/1.8 aperture, 28mm, 1/3" sensor size, optical image stabilization (OIS)
  • 12 MP Telephoto, f/2.8 aperture, 56mm, 2x optical zoom
  • Six-element lens, Quad-LED True Tone flash (50% brighter than iPhone 6s Plus)
  • Features: 10x digital zoom, Portrait mode (introduced via iOS 10.1), bokeh effect, autofocus, HDR, panorama, face detection, burst mode, Live Photos
  • Video: 4K at 30 fps, 1080p at 30/60 fps, 720p at 240 fps (slow-motion)
• Front Camera:
  • 7 MP FaceTime HD, f/2.2 aperture
  • Retina Flash, wide color capture
  • Features: HDR, face detection, burst mode
  • Video: 1080p at 30 fps
• Camera Notes:
  • Dual-camera system offers superior zoom and depth-of-field effects compared to iPhone 7
  • Improved low-light performance and color accuracy

Battery

• Capacity: 2900 mAh, non-removable Li-Ion
• Battery Life:
  • Varies by usage and network configuration
  • Up to 21 hours talk time (3G), 13 hours internet use (Wi-Fi), 12 hours internet use (LTE), 14 hours video playback, 60 hours audio playback
• Charging: Lightning connector, USB power adapter included
• Notes: Battery life may vary; liquid damage not covered under warranty

Connectivity

• Network:
  • 4G LTE Advanced, VoLTE (select markets)
  • GSM/CDMA models (depending on model number)
• Wi-Fi: 802.11 a/b/g/n/ac, dual-band, MIMO
• Bluetooth: v4.2, A2DP, LE
• NFC: Yes (for Apple Pay)
• Positioning: GPS, A-GPS, GLONASS, Galileo, QZSS
• SIM: Nano-SIM (no dual SIM or eSIM support)
• Notes:
  • Models A1661 (Qualcomm modem) have better performance than A1784/A1785 (Intel modem)
  • No 3.5mm headphone jack; includes Lightning EarPods and Lightning-to-3.5mm adapter

Audio

• Speakers: Stereo speakers (top earpiece + bottom speaker), twice as loud as iPhone 6s Plus
• Audio Features:
  • No 3.5mm headphone jack
  • Supports Lightning EarPods and Bluetooth audio
  • Single-channel mono audio for video recording
• Notes: Some units reported hissing noise during heavy usage, likely from A10 Fusion processor

Sensors

• Sensors:
  • Fingerprint sensor (Touch ID, embedded in solid-state Home button)
  • Accelerometer
  • Gyroscope
  • Proximity sensor
  • Ambient light sensor
  • Barometer
  • Compass
• Home Button: Solid-state, pressure-sensitive with Taptic Engine feedback

Software Features

• Preinstalled Apps: Pages, Numbers, Keynote, iMovie, GarageBand, iTunes U, Clips, Apple Store
• Supported Formats:
  • Images: .jpg, .tiff, .gif
  • Documents: .doc, .docx, .pdf, .ppt, .pptx, .txt, .rtf, .xls, .xlsx
  • Others: .htm, .html, .key, .numbers, .pages, .zip, .ics, .usdz
• Services: AirDrop, AirPlay, AirPrint, Screen Mirroring, FaceTime, iCloud, Siri, Spotlight Search
• Accessibility: Support for vision, hearing, motor skills, and literacy

Environmental and Operational

• Operating Temperature: 32° to 95°F (0° to 35°C)
• Non-operating Temperature: -4° to 113°F (-20° to 45°C)
• Environmental Impact: Apple GiveBack program for recycling; mercury-free, arsenic-free, BFR-free, PVC-free
• System Requirements:
  • iTunes 12.8 or later (Mac)
  • iTunes 12.9 or later (PC)
